2024 KTM 250 SX-F FACTORY RACING

2024 KTM 250 SX-F FACTORY EDITION dominates the class, being a reliable MX partner, able to highlight the potential of the most ambitious riders. The 250cc motocross model is distinguished at first sight by the glossy, orange 'FACTORY' frame, which comes equipped with Factory orange 2K protections. The factory package is completed by Factory spoilers for the fuel tank.

Other essential features of the Factory edition motorcycle include a front fender compatible with the offroad connectivity unit included as standard, black engine mounts, updated suspension settings and XACT air fork, ribbed Factory cover, RED BULL KTM FACTORY RACING graphics , orange CNC Factory triple clamps, semi-floating front brake disc, Factory front brake disc guard, soft ODI grips on gray, DID Factory rims, DUNLOP GEOMAX tires, WP Factory starter, Akrapovic Slip-On exhaust, Hinson clutch cover . A KTM motorcycle ready for competition! READY TO RACE!

The Offroad Connectivity Unit is a two-part system mounted between the right leg of the fork (protected by the shape of the plate) and the GPS component on the redesigned front fender. "UCO" allows easy-to-adjust options for engine behavior and suspension settings via the KTMConnect application. Official affiliation with LitPro gives riders the ability to examine lines, speed, throttle position and other data to achieve better times.

The 2024 KTM 250 SX-F FACTORY EDITION has the best 4-stroke unit in the paddock, with a SOHC engine that can be considered the perfect example of advanced engineering. The engine is tilted 2° to the rear, resulting in a 3mm lower position of the front pinion, which leads to an improved mass centralization. Mounted on special black "race" mounts (to help with chassis flex), with a maximum power of just over 47 HP and a total weight of only 26.1 kg, the engine will outperform the competition and has proven itself to be a true king of the holeshot at the MX2 Grand Prix. The Akrapovic slip-on exhaust adds an aesthetic bonus and, at the same time, reduces weight.

2024 KTM 250 SX-F FACTORY EDITION is a fast and competitive motocross. FACTORY tank spoilers improve cooling, the new tank mount has better contact with the frame, FACTORY orange frame guards increase grip, and the FACTORY 4-bolt skid plate and Hinson clutch cover are all high-impact parts that have were forged to save weight or dimensions, improving the racing experience.

Total traction. Selectable maps + TC
The map selection switch on the 2024 KTM 250 SX-F FACTORY EDITION has a simple design, allowing for easier functionality when changing from one map to another. Map 1 offers a more linear power curve, while Map 2 ensures aggressive acceleration and explosive power delivery. Power control can be activated or deactivated from the same switch, providing maximum traction and an advantage in wet or muddy conditions.

The 2024 KTM 250 SX-F FACTORY EDITION uses Launch Control and the Quickshifter function, allowing quick shifts from one gear to another without using the clutch. Launch Control is activated by simultaneously turning on the traction control and Quickshifter buttons and works by limiting the amount of power to the rear wheel, improving traction and preventing loss of control under strong acceleration.

The glossy orange frame is a key refinement of the 2024 KTM 250 SX-F FACTORY EDITION. Different wall thicknesses and sections improved the degree of flex and reduced a lot of weight. The chassis concept remains solid, and Red Bull KTM FACTORY RACING continues to win races and set records at the highest level based on the same principle. The chassis repositions the rotating mass closer to the center of gravity. The shock mount also provides anti-skid behavior to improve cornering traction, while the position of the step mount has been moved forward for less risk of snagging on roots or jumps.

The 2024 KTM 250 SX-F FACTORY EDITION features a refined rider triangle, providing improved knee contact - especially when riding down stairs - with improved grip surfaces all around. The plastic parts serve to remove accumulated mud in wet, muddy conditions. The FACTORY saddle with ribs and a flatter profile allows freedom of movement and great control. The aluminum subframe reinforced with polyamide improves the feedback to the rider.

WP XACT fork 48mm on the air, 310mm travel on the front offers confidence when the rider wants to attack the trail. Redesigned fork guards protect against mud.

Another upgrade is the harder and more rigid material of the rear brake pedal, which will unlock all the power of the Brembo system. The pedal is more resistant to unwanted contact and obstacles. The braking force is increased by the 260mm semi-floating disc on the front and the Factory brake protection reinforced with carbon.

The WP XACT shock offers unmatched consistency lap after lap, thanks to advanced damping features to ensure traction and energy absorption that is hard to match.

The 2024 KTM 250 SX-F FACTORY EDITION is rock solid at any speed thanks to the orange CNC machined anodized triple clamp. The clamps are made of high quality aluminum. Perfect geometry of the fork clamps for smooth action and quick response, plus great stability.

Technical details:

• engine 249.92 cc, 1 cylinder, 4 strokes
• 5-speed gearbox
• electric start
• tank 7.2 l
• front disc brake 260 mm
• rear disc brake 220 mm
• front suspension fork WP XACT-USD, Ø 48 mm, travel 310 mm
• rear suspension monoshock WP XACT, stroke 300mm
• to 958 mm
• ground clearance 343 mm.
